Name | Arrow-3 | MEADS | Pantsir-S1 MD | |
Radar Screen Layout |
|
|
| |
Radar Screen | Shape | Circle in Quadrangle | Quadrangle | Circle |
Location | Left of screen | Left of screen | Left of screen | |
Color (Background/Symbol) | Blue/White | N/A | Black/Red, Yellow | |
Text Info. | Shape | Window Box type | Window Box type | Window Box type |
Location | Right of screen | Right of screen | Right of screen | |
Color | N/A | N/A | Various Color | |
Tactical Map (Available/Resolution/Color) | Available/2D/Color | Available/2D/Color | Available/2D/Color | |
Number of Operator | 2 | 2 | 2 | |
Role | Radar detection, Targeting and Fire operation | Radar detection, Targeting and Fire operation | Radar detection, Targeting and Fire operation | |
Total Display | 4 | 4 | 2 |
